Power supply: AC 220V ~ 440V
Panel PC Boost Voltage: AC 220V
Slow Start: The output can be internal slow start
Capacity: 30A 40A 80A 60A 120A 100A 160A
Frequency: 50/60Hz
Output voltage: 0-97% output
Applicable load (A) load resistance
Applicable load (C): Resistance load, inductance load
Input signal: 4-20mA, 1-5V DC, 0-10V DC,
Cooling System: 40A 30A self-cooling
Ambient temperature: -10 ℃ ~ 55 ℃, humidity below 90%
Led Display: PL / Green LED - level indication
Error display (alarm output terminal)
Weight: approx 30A ~ 40A. 4 kg approx 60A. 4.5 kg
80A ~ 100A approx. 120A ~ 160A 5kg approx. 6 kg
